Advantage Of Pure Cast Iron Body
1. No Vibration In Comparison To Fabricated M.s Structure
2. Long Life : Can Say The Structure For Whole Life
3. Less Power Consumption
TC – 2500 | Multi Cutter |
Blade Dia. | Ø 2500 MM |
Cutting Depth | 1100 MM / 43” |
Max Blade Number | 10 Blade |
X – Axis Stroke | 5400 MM |
Y – Axis Stroke | 2200 MM |
Z – Axis Stroke | 1300 MM |
Main Motor | 75 HP |
Gross Weight | 13800 Kg |
Dimension [ L*W*H ] | 7890 x 4000 x 5850 MM |
TC – 2500 | Multi Cutter |
Blade Dia. | Ø 2500 MM |
Cutting Depth | 1100 MM / 43” |
Max Blade Number | 16 Blade |
X – Axis Stroke | 5400 MM |
Y – Axis Stroke | 2200 MM |
Z – Axis Stroke | 1300 MM |
Main Motor | 100 HP |
Gross Weight | 15800 Kg |
Dimension [ L*W*H ] | 7890 x 4500 x 5850 MM |
TC – 2500 | Multi Cutter |
Blade Dia. | Ø 2500 MM |
Cutting Depth | 1100 MM / 43” |
Max Blade Number | 20 Blade |
X – Axis Stroke | 5400 MM |
Y – Axis Stroke | 2200 MM |
Z – Axis Stroke | 1300 MM |
Main Motor | 120 HP |
Gross Weight | 16800 Kg |
Dimension [ L*W*H ] | 7890 x 5000 x 5850 MM |
